Full-port ball valve with packing nut on stem, with tail piece and aluminium butterﬂy handle

Product code
1452440

Dimensions
1/2"

Product line
Onyx

Go to technical data

25 years guarantee

For compressed air

For solar installations

For use in installations with glycol up to 50% concentration

Maximum pressure - PN 40

Maximum temperature - 180°C

Nickel-Free Anti-Allergy System

Key Product Features:

High valve durability
Seal-locking mechanism – a unique structural solution
Ergonomic aluminum butterfly handle
Suitable for use in compressed air systems
Suitable for use in chilled water installations
Anti-allergenic NICKEL-FREE system
Nominal pressure PN 40
Maximum operating temperature: 180°C
Minimum operating temperature: –20°C
Body made of CW617N brass

Technical data

	1452440
Dimentions	1/2"
Work parameters	PN 40, 180°C
Netto weight	0,18

Download

Catalogue card

PDF

308.33 KB

Guarantee card

PDF

5328.87 KB

National Declaration of Performance (PL)

PDF

133.79 KB

Hygienic certificate (PL)

PDF

301.15 KB

Instructions

PDF

1056.13 KB
